FIND. TRACK. LOG.

TRACKING EVENTS
Asset tracking, Staff tracking, Sensor tracking, Customer tracking, Tool tracking, Vehicle tracking, Movement patterns
BEACON OVSERVER MODE
Tracking
BEACON OBSERVER MODE is one of three modes.
The Gateway is connected to one single line of BEACON LINE ANCHORS.
The system offers simple and flexilble installations. This is just an example to show the structure of the BEACON LINE.

BEACON LINE STARTERKIT
| |
---|
9 Nodes | Enables yo a set-up of nodes to a 3x3 "S"-line grid or any other free grid forms. |
1 Wi-Fi/Ethernet Gateway | Routes the data between the nodes and your Wi-Fi or ethernet network. |
3 Beacons | Lets you operate and test the Beacon-Line immediately. |
10 Cables, each 5m long | Connects all nodes and the gateway in one line and serves for the power supply. |
1 Power-supply | Supplies the Beacon-Line with power centrally. |
1 Software package | Beacon-Line-Explorer based on QT (Qt is a cross-platform application framework) |
FLEXIBLE INSTALLATION | SAFE MONEY | HIGH SCALABILITY |
---|
The modular system offers you simple and flexible installations. It is designed also for easy integration into existing facility systems and electrical insallations. | Save 8% and more cost to comparable hardware (mini CoM) in the first year. Save approx. 95% less power consumption costs. Save much money as from the third year instead of installing standard iBeacon. | Due to its architecture the network can be scaled cost-effective to any size. Just plug additional Beacon Line anchors to an existing line or create a new line easily. |
BATTERY FREE | OPEN FOR DEVELOPERS | OPEN FOR IDEAS |
---|
The Beacon Line´s power supply comes from one central power suply module for each line. No battery is required. You avoid unexcpected cost rist in large scale deployment for batteries and its replacement and be over 100% mor exologically friendly. | All BEacon packages are transmitted transpatantly for flexible reuse and processing. Each node is mapped to a serial TTY or COM port and thus individually programmable, configurable and addressable. The gateay can connect to MQTT servers for publish/subscribe services and for web-based appliances. | The sky´s the limit. Feel free to think about any wireless user or machine application. The node line concept ist open for great ideas. We offer solutions for integrating devices like sensors and acutators or other wireless technologies like Zigbee, NFC, MBus, KNX, 6LoWPAN etc. |
